• Bumper, front, chrome, with Gray lower
• Bumper, rear, chrome step, includes pad
• Air dam, Gray
• Moldings, bodyside (Moldings are color-keyed and not available with (ZW9) Pickup bed delete. - Refer to Color and Trim Chart for compatibility)
• Wheel flares (Refer to Color and Trim chart for compatibility. -Front only when (ZW9) Pickup bed, delete is ordered)
• Grille, color-keyed surround, with chrome accent bar
• Headlamps, dual halogen composite, includes flash-to-pass feature and automatic lamp control
• Daytime running lamps, includes automatic exterior lamp control
• Lamps, dual cargo area lamps
• Fog lamps, front, halogen
• Mirrors, outside rearview, power folding, power, heated, Black, driver side electrochromic (light-sensitive auto-dimming) and turn signal in glass (Upgradeable to (DPN) Mirrors, vertical camper, outside rearview. - Includes curb-tilt when (UK3) Sound system feature, steering wheel mounted radio controls is ordered)
• Glass, Solar-Ray deep tinted (all windows except light tinted glass on windshield) (With Extended Cab Models, includes rear window and rear quarter windows. - With (C49) Defogger, rear-window, electric, includes light-tinted rear)
• Wipers, intermittent, front, wet-arm with pulse washers

• Seat trim, leather (Not available on Regular Cab Models. - Extended Cabs includes front leather seating surfaces with rear vinyl bench. - Crew Cab includes front and rear leather appointed seating surfaces)
• Seats, front power reclining full-feature buckets, includes adjustable head restraints, floor console, driver and passenger 2-way power lumbar, driver and front passenger 10-way power adjustable, dual inboard armrests, heated driver and passenger cushion and back, 2-position driver-side memory and storage pockets
• Seats, rear bench, folding, 3-passenger (includes child seat top tether anchor) (Not available with Regular Cab Models.)
• Seat adjuster, power, driver 6-way (With (AN3) Seats, front power reclining full-feature buckets, includes 10-way adjuster)
• Seat adjuster, power, front passenger 10-way (Included and only available with (AN3) Seats, front power reclining full-feature buckets.)
• Console, floor, includes storage compartment and dual cupholders
• Steering wheel, leather-wrapped rim, Black, includes theft-deterrent locking feature
• Theft-deterrent system, PASSlock II
• Driver Information Center, monitors numerous systems depending on vehicle equipment
• Warning tones, headlamp on, key-in-ignition, driver and passenger buckle-up reminder, turn signal on
• Defogger, rear-window, electric (Not available with (A28) Window, rear sliding)
• Cruise control, electronic with set and resume speed, includes telltale in instrument panel cluster
• Door locks, power
• Windows, power, includes driver and passenger express-down
• Keyless entry, remote, includes 2 transmitters, panic button and content theft alarm
• Air conditioning, dual-zone, automatic, individual climate settings for driver and right front passenger (Must be substituted with (CJ3) Air conditioning, dual-zone, manual when (VYU) Snow Plow Prep Package is ordered.)
• Sound system, ETR AM/FM stereo with 6-disc CD changer, includes seek-and-scan, digital clock, auto-tone control, speed-compensated volume, TheftLock, Radio Data System (RDS), and Bose speaker system (includes 6 speakers, Bose amplifier and Bose Subwoofer)
• Sound system feature, Bose Premium speaker system
• Sound system feature, steering wheel mounted radio controls, Radio and Driver Information Center (DIC). Provides access to enhanced Driver Information Center (DIC) features and information
• Sound system feature, rear audio controls, includes dual headphone jacks (headphones not included), power outlet and controls for volume, station selection and media (Requires Crew Cab Models)
• Cupholders, front (Also includes rear cupholders on Extended and Crew Cab Models.)
• Cigarette lighter, on instrument panel
• Power outlets, auxiliary, covered, 2 dash-mounted, 12-volt
• Mirror, inside rearview, electrochromic (light-sensitive auto dimming), 8-point compass and outside temperature indicator
• Visors, padded, Shale-colored, driver and passenger side with cloth trim, extenders, pocket on driver side and vanity mirror on passenger side
• Console, overhead mini, includes map lights (Not available with (CF5) Sunroof, power)
• Assist handle, front passenger (Also includes rear outboard passenger assist on Extended and Crew Cab Models.)
• Coat hook, driver side (Also includes passenger side coat hook on Extended and Crew Cab Models.)
• Lighting, dome lamp, reading, backlit instrument panel switches and door handle-activated illuminated entry

• Brakes, 4-wheel antilock, 4-wheel disc
• Air bags, frontal, driver and right front passenger (Regular and Extended Cab Models includes passenger side deactivation switch. - Always use safety belts and proper child restraints, even with air bags. Children are safer when properly secured in a rear seat. See the Owners Manual for more safety information)
• Daytime running lamps, includes automatic exterior lamp control

LT3 PREFERRED EQUIPMENT GROUP

• Includes Standard Equipment

SEATS, FRONT POWER RECLINING FULL-FEATURE BUCKETS

• includes adjustable head restraints
• floor console
• driver and passenger 2-way power lumbar
• driver and front passenger 10-way power adjustable
• dual inboard armrests
• heated driver and passenger cushion and back
• 2-position driver-side memory and storage pockets (STD)

GVWR, 9200 LBS. (4173 kg)

• (STD)

MIRRORS, VERTICAL CAMPER, OUTSIDE REARVIEW, POWER ADJUSTABLE GLASS, HEATED, MANUAL FOLDING AND EXTENDING

• includes turn signal indicators and lower convex spotter glass (convex glass is not heated)

ENGINE BLOCK HEATER

• (Included with (LLY) Engine
• Duramax 6600 Turbo Diesel V8 or (LBZ) Engine
• Duramax 6600 Turbo Diesel V8.)

AIR CLEANER, HIGH-CAPACITY

• (Included with (LLY) Engine
• Duramax 6600 Turbo Diesel V8
• (LBZ) Engine
• Duramax 6600 Turbo Diesel V8
• (Z82) Trailering equipment
• heavy-duty and (VYU) Snow Plow Prep Package)

ENGINE, DURAMAX 6600 TURBO DIESEL V8

• (360 HP [268.0 kW] @ 3200 rpm
• 650 lb.-ft. [881.0 N-m] @ 1600 rpm) Includes (TQ3) Battery
• heavy-duty dual
• 770 cold-cranking amps
• (KG3) Alternator
• 145 amps
• (K47) Air cleaner
• high capacity and (K05) Engine block heater)

TRANSMISSION, ALLISON 1000 6-SPEED AUTOMATIC, ELECTRONICALLY CONTROLLED WITH OVERDRIVE AND ELECTRONIC ENGINE GRADE BRAKING

• includes tow/haul mode selector and (KNP) Cooling
• external transmission oil cooler

SKID PLATE PACKAGE

• includes aluminum front underbody shield starting behind front bumper and running to 1st cross-member
• protecting front underbody
• oil pan
• differential case and transfer case
• frame-mounted shields -Included with (VYU) Snow Plow Prep Package.)

ONSTAR PLUS PACKAGE

• includes (U2K) Sound system feature
• XM Satellite Radio
• (UE1) OnStar
• and (UK3) Sound system feature
• steering wheel mounted radio controls

HEAVY-DUTY POWER PACKAGE

• includes (LBZ) Engine
• Duramax 6600 Turbo Diesel V8
• (MW7) Transmission
• Allison 1000 6-speed automatic and (G80) Differential
• locking
• heavy-duty
• rear

TIRES, LT245/75R16E, ALL-SEASON, BLACKWALL

• (STD) (Includes 5 tires with (E63) Pickup bed
• Fleetside box. -Includes 4 tires with (ZW9) Pickup bed
• delete)

SPARE TIRE LOCK

• keyed cylinder lock that utilizes same key as ignition and door

BATTERY, HEAVY-DUTY DUAL, 770 COLD-CRANKING AMPS

• includes rundown protection and retained accessory power

SOUND SYSTEM FEATURE, XM SATELLITE RADIO

• features 67 channels of 100% commercial-free music included in its over 150 channels of the best in music
• news
• sports
• talk
• comedy
• XM Instant Traffic and Weather
• and more. Digital quality sound with coast-to-coast signal coverage. Three trial months-no obligation

SOUND SYSTEM, ETR AM/FM STEREO WITH 6-DISC CD CHANGER

• includes seek-and-scan
• digital clock
• auto-tone control
• speed-compensated volume
• TheftLock
• Radio Data System (RDS)
• and Bose speaker system (includes 6-speakers
• Bose amplifier and Bose Subwoofer) (STD)

ONSTAR, ONE-YEAR OF SAFE AND SOUND SERVICE

• Includes Automatic Notification of Air Bag Deployment
• Emergency Services
• Stolen Vehicle Location Assistance
• Remote Door Unlock
• OnStar Vehicle Diagnostics
• Roadside Assistance
• Accident Assist and Remote Horn and Lights. Also featuring Hands-Free Calling.

TRAILERING EQUIPMENT, HEAVY-DUTY

• includes trailering hitch platform
• 7-wire harness (harness includes wires for: park lamps
• backup lamps
• right turn
• left turn
• electric brake lead
• battery and ground) with independent fused trailering circuits mated to a 7-way sealed connector
• instrument panel jumper wiring harness for electric trailer brake controller
• and 1-way sealed connector for center high-mounted stop/brake lamp. Also includes (K47) Air cleaner
• high capacity

PAINT, SOLID

• (STD)

• Heavy-Duty Handling/Trailering Suspension Package
• 6 Speakers
• AM/FM radio
• CD player
• Radio data system
• Air Conditioning
• Dual-Zone Automatic Air Conditioning
• Electric Rear-Window Defogger
• Front dual zone A/C
• Rear window defroster
• Power steering
• Power windows
• Power Windows w/Driver & Passenger Express-Down
• Remote keyless entry
• 4-Wheel Disc Brakes
• ABS brakes
• Dual front impact airbags
• Front anti-roll bar
• Front wheel independent suspension
• Power Door Locks
• Front Halogen Fog Lamps
• Fully automatic headlights
• Panic alarm
• Remote Keyless Entry w/2 Transmitters
• Security system
• Electronic Cruise Control w/Set & Resume Speed
• Speed control
• Black Power Folding Outside Rear-View Mirrors
• Bodyside moldings
• Bumpers: chrome
• Color-Keyed Bodyside Moldings
• Electronic Shift Transfer Case
• Heated door mirrors
• Power door mirrors
• Rear Chrome Step Bumper w/Pad
• Rear step bumper
• Auto-dimming Rear-View mirror
• Black Leather-Wrapped Steering Wheel Rim
• Color-Keyed Carpeting & Floormats
• Compass
• Driver door bin
• Electrochromic Inside Rear-View Mirror
• Front reading lights
• Illuminated entry
• Leather steering wheel
• Outside temperature display
• Overhead console
• Overhead Mini Console w/Map Lights
• Passenger vanity mirror
• Rear seat center armrest
• Steering Wheel Mounted Radio Controls
• Tachometer
• Tilt steering wheel
• Voltmeter
• Leather Seat Trim
• Split folding rear seat
• Passenger door bin
• 16" x 6.5" Polished Forged Aluminum Wheels
• Solar-Ray Deep Tinted Glass
• Variably intermittent wipers
• 4.10 Rear Axle Ratio

• Electrical
• Cold Cranking Amps @ 0° F (Primary): 770
• Cold Cranking Amps @ 0° F (Primary): 600
• Cold Cranking Amps @ 0° F (2nd): 770
• Maximum Alternator Capacity (amps): 105
• Cooling System
• Total Cooling System Capacity (qts): - TBD -
• Total Cooling System Capacity (qts): 16.0
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 4670
• Gross Axle Wt Rating - Rear (lbs): 6084
• Curb Weight - Front (lbs): 3331
• Curb Weight - Rear (lbs): 2424
• Gross Vehicle Weight Rating Cap (lbs): 9200
• Gross Combined Wt Rating (lbs): 22000
• Gross Combined Wt Rating (lbs): 16000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 12000
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 9800
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1500
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1470
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 14200
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 9800
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 3550
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 2450
• Suspension
• Suspension Type - Front: Torsion Bar
• Suspension Type - Rear: 2-Stage Multi-Leaf
• Spring Capacity - Front (lbs): 4800
• Spring Capacity - Rear (lbs): 6084
• Axle Type - Rear: Full-Floating
• Axle Capacity - Front (lbs): 4800
• Axle Capacity - Rear (lbs): 6900
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 3.73
• Axle Ratio (:1) - Rear: 4.10
• Shock Absorber Diameter - Front (mm): 36
• Shock Absorber Diameter - Rear (mm): 36
• Stabilizer Bar Diameter - Front (in): 1.42
• Brakes
• Brake Type: Pwr
• Brake ABS System: Four-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.8 x 1.5
• Rear Brake Rotor Diam x Thickness (in): 13 x 1.1
• Tires
• Front Tire Order Code: QIZ
• Rear Tire Order Code: QIZ
• Spare Tire Order Code: ZHH
• Spare Tire Order Code: QIZ
• Front Tire Size: LT245/75R16
• Rear Tire Size: LT245/75R16
• Spare Tire Size: LT245/75R16
• Front Tire Capacity (lbs): 2335
• Rear Tire Capacity (lbs): 3042
• Spare Tire Capacity (lbs): 2335
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 16 x 6.5
• Rear Wheel Size (in): 16 x 6.5
• Spare Wheel Size (in): 16 x 6.5
• Front Wheel Material: Aluminum
• Rear Wheel Material: Aluminum
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr
• Steering Ratio (:1), On Center: - TBD -
• Steering Ratio (:1), At Lock: - TBD -
• Turning Diameter - Curb to Curb (ft): 49.6
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 26
• Fuel Tank Location: LH
• Exterior Dimensions
• Wheelbase (in): 153.0
• Length, Overall w/o rear bumper (in): 239.7
• Width, Max w/o mirrors (in): 79.7
• Height, Overall (in): 77.0
• Overhang, Front (in): 37.0
• Overhang, Rear w/o bumper (in): 52.2
• Front Bumper to Back of Cab (in): 148.1
• Cab to Axle (in): 41.9
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): - TBD -
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): 10.6
• Ground Clearance, Rear (in): 13.6
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 78.7
• Cargo Box Width @ Top, Rear (in): 61.9
• Cargo Box Width @ Floor (in): 64.8
• Cargo Box Width @ Wheelhousings (in): 50.0
• Cargo Box (Area) Height (in): 19.5
• Tailgate Width (in): 61.9
• Cargo Volume (ft³): 56.9
• Ext'd Cab Cargo Volume (ft³): - TBD -
• Interior Dimensions
• Passenger Capacity: 6
• Front Head Room (in): 41.0
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 65.2
• Front Hip Room (in): 61.4
• Second Head Room (in): 39.0
• Second Leg Room (in): 39.1
• Second Shoulder Room (in): 65.1
• Second Hip Room (in): 62.9
• Summary
• Vehicle Name: Chevrolet Silverado 2500HD
• Body Style: Crew Cab 6.5' Fleetside
• Body Code: E63
